| Product Name: | Heat Exchanger Plate & Gaskets | Gaskets Material: | NBR, HNBR,EPDM,VITON |
|---|---|---|---|
| Application: | Heater Parts | Transfer Area: | 0.094㎡ |
| Dimension: | Centre To Centre: 704mm*90mm | Roller: | 30mm |
| High Light: | neoprene gasket,viton gasket |
||
Product Description
We make heat exchanger gaskets on stock in order to provide the fastest delivery times in the business. With such a large inventory, we can supply gaskets for highly specialized unit requirements. We manufacture OEM-specified heat exchanger gaskets unlike competitors who are simply resellers.FDA-approved versions of NBR and EPDM are standard for us. We use imported Vtion raw materials to ensure the superior quality. The models we provide can replace the world famous manufacturers.
| Gasket Material | Temperature Range ( ℃) | Hardness | Available Medium |
| NBR | -20 to 110 | -75+/-3 | Water, Oil, Acid etc |
| EPDM | -30 to 150 | 80+/-5 | Steam, Ammonia, Acid etc |
| NBR-HT | -30 to 160 | 85+/-5 | Mineral Oil, Thermal Oil |
| EPDM-HT | -30 to 180 | 85+/-5 | High temperature water |
| TFEP | -20 to 180 | 80+/-5 | Acid,Glycol,Chloride |
| FPM | -55 to 220 | 80+/-5 | Acid,Glycol,Chloride |
Gasket Features
M&C gaskets can be designed to different assembing type, Such as glue-on,clip-on,snap-on,ball-in etc.
High Quality--- The rubber material are mixed in closed space with controllable pressure and temperature which ensure high production efficiency and excellent quality. Spare parts surface contact with rubber material is polished anti-corrosion.
Reasonable Design--- Parameters of equipment are designed reasonably to distribute material evenly.
Easy To Use--- Adding rubber material from the back door of the equipment, mixing room turns forward by 140°to finish and make the cleaning of room easy.
PLC Controller---PLC controller has perfect controlling function,testing and alarming function and safety secure function,serial interface.
PHE Principle
Flat plate heat exchanger is a type of heat exchanger that uses metal plates to transfer heat between two fluids.This has a major advantage over a conventional heat exchanger in that the fluids are exposed to a much larger surface area because the fluids spread out over the plates. This facilitates the transfer of heat, and greatly increases the speed of the temperature change. Plate heat exchangers are now common and very small brazed versions are used in the hot-water sections of millions of combination boilers. This high heat transfer efficiency for such a small physical size has increased the domestic hot water(DHW) flow rate of combination boilers. The small plate heat exchanger has made a great impact in domestic heating and hot-water.Larger commercial versions use gaskets between the plates.
Payment
Standard payment terms: 100% in advance.
Pay 30% deposit in advance, 70% balance before shipment.
More payment terms could be provided (T/T, WESTERN UNION)
Shipping
Delivery time: 5-8 working days after payment receipt confirmed (based on actual quantity)
Packing: standard export packing, or customized packing as your request.
Professional goods shipping forwarder.
Why choose us
Strict QC system
Professional team
Competitive price
Fast delivery
Good after-sales service
