| Gasket Material: | EPDM/NBR/HNBR/VITON/FPM | Plate Material: | AISI 304/ AISI 316L/ Titanium/ TiPA/SMO254/ Alloy 904/ Nickel |
|---|---|---|---|
| Plate Thickness: | 0.5/0.6mm | Plate Theta: | Only Low Theta |
| Plate Shape Dimension: | 992*476mm | Transfer Area: | 0.35㎡ |
| Plate Center Dimension: | Centre To Centre: 800mm*283mm | Hole Diameter: | 145mm |
| Max Pressure: | 25 Bar | Temperature Range: | 0-220 ℃ |
| High Light: | donghwa s35 heat exchanger gasket,0.5mm heat exchanger gasket,0.5mm donghwa s35 gasket |
||
Marine industry M/E JACKET F.W COOLER GLUE TYPE STAINELESS STEEL 316L 0.5mm Plate Heat Exchanger Sondex/Donghwa S35
MC Plate Heat Exchanger Main Components
1. Head for connections and clamping the plate pack
2. Follower for clamping the plate pack
3. End support for supporting the top and bottom bars
4. Top bar for carrying and guiding the follower and plate pack
5. Bottom bar for guiding the follower and plate pack
6. Tie bars for clamping the plate pack between head and follower
7. Flow plate (Figure 1)
8. Flow gasket (Figure 1)
9. Nut for tie bar
10. Adjustable or fixed legs
11. Connector grid for additional fluid connector bosses
12. Connector bosses
H17 Gasket Parameter
| Rubber Type | NBR | EPDM | VITON/FKM | HNBR |
| Application Temperature | -20°C- +130°C | -50°C-+150°C | -30°C-+251°C | -15°C- +160°C |
| Fluid Media |
Water Sea water Mineral oil Salt brine |
Hot water Steam Acid Alkali |
High temperature resistance Strong oxidants Oil Acid and alkali |
High temperature mineral oil and water |
| Feature | Easier to replace than the traditional gasket, high pressure, high temperature, longer life, should not be leaked | |||
| Material of Gasket | Operating Temperature(℃) | Suited Liquid kinds |
| NBR | -15 to +135 | Water,sea water etc |
| EPDM | -25 to +180 | Hot water,steam etc |
| FPM/VITON | -55 to +230 | Acid,Caustic,Fluid |
| HNBR | 0 to +160 | Concentrated acid etc |
