Product Details:
Payment & Shipping Terms:
|
| Install Type: | Glue/Hang-on/Clip-on/Snap-on/Sonderlock | Material: | NBR/EPDM/HNBR/HEPDM/VITON/FKM |
|---|---|---|---|
| Thickness: | 0.8/1.0mm | Brand Name: | Sigma 96 |
| Structure: | Plate Heat Exchanger | Weight: | STANDARD |
| Condition: | New | Plate Material: | 316L,Titanium,SS304,254SMO,Nickel |
| High Light: | Food Grade HNBR Gasket,Sigma 96 HNBR Gasket,Marine sigma gasket |
||
Sigma96 Structure
M&C plate heat exchanger is composed of a certain number of gaskets, they fixed between the top bearing bar and lower guide rod. Plate with fixed frame plates (head) and movable framework (follower) the connection between the rod is compressed. Connect the fluid through the framework into the plate heat exchanger and distribution between the plates. Through board alternate between channel flow control by place the gasket. These can be single line and multiple lines arrangement, depends on the application.
Sigma 96 Heat Exchanger Rubber Gasket Material
| Material | Temperature Range | Operating Conditions |
| NBR gasket | ≤135℃ | Nonpolar media such as resistance to mineral, animal and vegetable oil |
| HNBR gasket | -5℃-150℃ | Sour crude oil resistant, containing H2S mixed dielectric, high temperature cooking oil and other nonpolar medium |
| EPDM gasket | ≤160℃ | Hot water, steam, food beverage, milk high-temperature sterilization |
| Solvnt EPDM gasket | -20℃-150℃ | Volume, and other good solvent polarity solvent such as lipids, inorganic acid and alkali, etc |
| General fluoro rubber gasket | ≤180℃ | Nonpolar mineral oil, lubricating oil containing alcohol fuel, etc |
| Special fluoro rubber gasket | -30℃-130℃ | High concentration of sulfuric acid and other inorganic oxyacid |
| Note: the above analysing all have corresponding food-grade gasket. |
||
Sigma 96 Heat Exchanger Rubber Gasket Material
| Material | Temperature Range | Operating Conditions |
| NBR gasket | ≤135℃ | Nonpolar media such as resistance to mineral, animal and vegetable oil |
| HNBR gasket | -5℃-150℃ | Sour crude oil resistant, containing H2S mixed dielectric, high temperature cooking oil and other nonpolar medium |
| EPDM gasket | ≤160℃ | Hot water, steam, food beverage, milk high-temperature sterilization |
| Solvnt EPDM gasket | -20℃-150℃ | Volume, and other good solvent polarity solvent such as lipids, inorganic acid and alkali, etc |
| General fluoro rubber gasket | ≤180℃ | Nonpolar mineral oil, lubricating oil containing alcohol fuel, etc |
| Special fluoro rubber gasket | -30℃-130℃ | High concentration of sulfuric acid and other inorganic oxyacid |
| Note: the above analysing all have corresponding food-grade gasket. | ||
Gasket Content
Special design of double sealing gasket sealing pore structure and signal, can ensure the sealing gasket is damaged, the medium from the first line of the seal leak can through early detection signal leakage problem to solve in time, will not result in a mixture of two kinds of heat transfer medium, avoid and reduce the losses caused by medium leakage.
Card button or buckle type to avoid glue sealing gaskets gasket longer service life, change is more quick and convenient, greatly reduce the maintenance cost and maintenance downtime. For sealing gasket seal with fixed function separation, even if part of the fixed function card button or buckle down, gasket can still play a role of sealing in the gasket groove.
Roof type geometry appearance make the rubber gasket enhanced ability to resist stress and vibration resistance, longer sealing force, longer service life, reduced maintenance costs.
Our Advantage
EXCELLENT QUALITY LONG-TERM TECHNICAL SUPPORT
We supply service from PHE assembling to technical consultation.We have built a long service relationship with customers since the order confirmed.
Sigma 96 After-sales service
1, M&C has experienced emergency repair team which enables us to provide on-time maintenances.
2, Within warranty period,M&C will provide free maintenance for any break up due to importer wrong operation or natural damage.Materials and parts for maintenance are charged only with lowest cost.
3, We will trace the operation of our product and record the feedback from our customs.
4, Adhere to the principle of “Customer Supreme, Quality First”,our technicians learn the maintainance training regularly. We supply free technical support and service in order to make our customers satisfied.
Package:standard export carton, plywood case
