Product Details:
Payment & Shipping Terms:
|
| Product Name: | Heat Exchanger Plate & Gaskets | Gaskets Material: | NBR, HNBR,EPDM,VITON |
|---|---|---|---|
| Type: | Plate Heat Exchanger With Gaskets | Application: | Heater Parts |
| Transfer Area: | 0.259㎡ | Dimension: | Centre To Centre: 980mm*174mm |
| High Light: | neoprene gasket,viton gasket |
||
Product Details
Plate heat exchanger AND Plate with gaskets for sale.
Plate and frame heat exchangers, titanium heat transfer plate, NBR/EPDM gasket.
Plate Quality
| Material | Fluid Media |
| Stainless steel(Alloy 304,Alloy 316) | Water, river water, edible oil, mineral oil |
| Ti,Ti-Pd | seawater, brine, and chloride |
| 20Cr,18Ni,6Mo(254SMO) |
sulfuric acid, sparse salified aqueous solution, an aqueous solution of an inorganic |
| Ni |
High temperature, high concentration caustic soda |
| HASTELLOY(C276,D205,B2G) | concentrated sulfuric acid, hydrochloric acid,phosphoric acid |
Gasket Quality
| Rubber Type | NBR | EPDM | VITON/FKM | HNBR |
| Application Temperature | -20°C- +130°C | -50°C-+150°C | -30°C-+251°C | -15°C- +160°C |
| Fluid Media |
Water Sea water Mineral oil Salt brine |
Hot water Steam Acid Alkali |
High temperature resistance Strong oxidants Oil Acid and alkali |
High temperature mineral oil and water |
| Feature | Easier to replace than the traditional gasket, high pressure, high temperature, longer life, should not be leaked | |||
Packing and shipping
Packiaging:Normal we use standard export pallet or carton . the pallet and wood box are easy for the forklift to transfer. We choose the packing method as your requirement.
Shipping: The delivery period of our products depends on the type, size and quantity etc. and the detailed days should be confirmed after we confirm all the information above.
