Product Details:
Payment & Shipping Terms:
|
| Structure: | Plate Heat Exchanger,PHE, Gasketed PHE, Frame Type Heat Exchanger | Plates Material: | HEPDM |
|---|---|---|---|
| Product Name: | European And American Quality Of Brazed Acid Resistant NBR R8 For Plate Heat Exchanger Head Pad Intermediate Pad | Weight: | 70g |
| Mark Color: | Red/Blue/White | Design: | According Tranter Original Made, Replace Original Product |
| Highlight: | EPDM Phe Tranter Heat Exchanger Gaskets,Heat Exchanger Gaskets Eco Friendly,Acid Resistant Heat Exchanger Gaskets |
||
Heat Exchanger Rubber Gasket Material
| Material | Temperature Range | Operating Conditions |
| NBR gasket | ≤135℃ | Nonpolar media such as resistance to mineral, animal and vegetable oil |
| HNBR gasket | -5℃-150℃ | Sour crude oil resistant, containing H2S mixed dielectric, high temperature cooking oil and other nonpolar medium |
| EPDM gasket | ≤160℃ | Hot water, steam, food beverage, milk high-temperature sterilization |
| Solvnt EPDM gasket | -20℃-150℃ | Volume, and other good solvent polarity solvent such as lipids, inorganic acid and alkali, etc |
| General fluoro rubber gasket | ≤180℃ | Nonpolar mineral oil, lubricating oil containing alcohol fuel, etc |
| Special fluoro rubber gasket | -30℃-130℃ | High concentration of sulfuric acid and other inorganic oxyacid |
| Note: The above analysing all have corresponding food-grade gasket. | ||
Applications
1. Chemical industry: manufacturing titanium oxide, alcoholic fermentation, synthesis, synthetic ammonia, resin manufacturing rubber, cooling, cooling water, alkali formaldehyde carbon phosphate industry, electrolytic alkali production.Iron and steel industry cooling quenching oil, cooling with electroplating liquid, cooling speed reducer lubricating oil, rolling machine, wire drawing machine, cooling liquid cooling.
2. Metallurgical industry: aluminate liquor heating and cooling, cooling sodium aluminate, aluminium rolling mill oil cooling.
3. Machinery industry: all kinds of quenching liquid cooling, lubricating oil cooling machine, industrial machine tools, heat engine oil.
4. Food industry: salt, milk, soy sauce, vinegar, sterilization, cooling, animal and plant oil heating, cooling, beer, wort in beer production, cooling/heating sugar, gelatin concentration, sterilization, cooling, monosodium glutamate.
5. Textile industry: all kinds of waste heat recovery, boiling phosphating fiber cooling, cooling viscose, acetic acid and acetic anhydride cooling, cooling the aqueous alkali, viscose filament heating and cooling.
6. Paper industry: cooling blackwater, bleaching with salt and alkali, heating, cooling, cellophane waste heat recovery, heating cooking acid cooling naoh aqueous solution, bleaching paper recycling waste liquid, exhaust gas condensation, preheat concentrated pulp waste liquid.Central heating, thermal power plant waste heat district heating, heating water, heating boiler area
7. Oil industry: heating, cooling, synthetic detergent, heating oil, vegetable oil cooling, cooling and sodium hydroxide, glycerin, emulsified oil cooling.
8. Electric power industry: the generator shaft pump cooling, transformer oil cooling.
9. Marine Industry: marine diesel engines central cooler, discharging water cooler, cooler, oil cooler, preheater, seawater desalination system (including multiple and single stage)
10. Other: medicine, oil, ceramics, glass, cement, geothermal, etc.
Why Choose us?
FAQ
-----Yes, we’d like to produce our customers’ OEM/ODM orders.
----- Equipment: 1 set Plate/Gasket :20 pcs
----- We are one of the professional plate heat exchanger factory in China, best production capability,best control,best service.
----- 1 year after the machines arrived in customer’s factory.
----- Under normal conditions, we don’t accept such orders. But if we have good business relation with the customer, we’ll consider to suit the condition.
